Description
ALL POSTED PRICES ON TRAILERS ARE DISCOUNTED FOR CASH OR CHECK ONLY SALES! ANY OTHER FORM OF PAYMENT THE TRAILER WILL BE SOLD AT FULL RETAIL PRICE!
3′ SIDE WALLS
17,500 GVWR
Standard Equipment
2 – 8000# Dexter
215/75R/17.5 LRH
8000#
17500#
2 – Electric Brakes Nev-R-Adjust
7×16 DPX 175
E-Z Lube – 1/2 Cambered
Coupler: 2 5/16″ Forged Adjustable 5/Position
Coupler: 2 5/16″ Round Adjustable on GN
Jack: 10000# Drop Leg
Jack: Dual 10000# Drop Leg on GN
Fenders: HD Diamond Plate Straight
Floor: 7 GA Sheet Metal
Width: 83″ Inside Box
Brake: Electric All Wheel
Break Away Unit w/Charger
DOT Reflective Tape
Primed & Painted Underside
Doors: Double Action (Dual Swing Out/Spreader Gate. NA w/High Sides.)
Ramp Pockets w/7′ Ramps
5/8″ D-Rings in Box (4)
Spare Rack
Sealed Flush Mount LED Lights
Wiring Harness
Lockable Battery/Pump Box
Deep Cycle 12V Marine Battery w/110V-5 Amp Charger
Color: Black
Frame Structure
Frame & Tongue: 8″ I-Beam Intergrated
Neck & Risers: (GN Model) 10″ I-Beam
Sides: 36″ Tall 10 GA Sheet Metal w/Toprail
Toprail: Rigid 3×2 Rectangular Tubing
Uprights: 24″ OC
Dump Body Frame: 6″ Channel
Crossmembers: 3″ Channel 16″ OC
Tarp Bracket & Tie Downs
Loading Height 4″ Lower than DP Model
Dump Components
Hoist: Scissor Lift
Power Up/Power Down
Control: Pistol Grip w/10′ Cord
Safety Prop
Caulked Seams on Dump Body
